Install Excalidraw Self-hosted (Docker)

Excalidraw Whiteboard

• Excalidraw is a virtual whiteboard that even provides a workspace for live collaboration, enabling real-time interaction with colleagues / Team
• Excalidraw is a free, open-source, browser-based sketching tool.
• Free your idea
• Third-party libraries help you visualize your idea, but you have not found libraries that fit your requirements. You can create and share it.

Install Excalidraw Self-hosted

- docker container

docker pull excalidraw/excalidraw:latest
docker run -d -p 8888:80 --name excalidraw-instance excalidraw/excalidraw:latest

- https with traefik + docker compose

• Create a docker-compose.yml

	version: '3.3'
	services:
	traefik2:
	image: traefik:latest
	restart: always
	command:
	- "--log.level=DEBUG"
	- "--api.insecure=true"
	- "--providers.docker=true"
	- "--providers.docker.exposedbydefault=true"
	- "--entrypoints.web.address=:80"
	- "--entrypoints.websecure.address=:443"
	- "--entrypoints.web.http.redirections.entryPoint.to=websecure"
	- "--entrypoints.web.http.redirections.entryPoint.scheme=https"
	ports:
	- 80:80
	- 443:443
	networks:
	traefik:
	volumes:
	- /var/run/docker.sock:/var/run/docker.sock
	container_name: traefik
	excalidraw:
	image: excalidraw/excalidraw:latest
	restart: always
	networks:
	traefik:
	environment:
	- LOG_LEVEL=debug
	labels:
	- "traefik.enable=true"
	- "traefik.http.routers.excalidraw.tls=true"
	- "traefik.http.routers.excalidraw.rule=Host(`excalidraw.cloud.local`)"
	- "traefik.http.routers.excalidraw.entrypoints=websecure"
	- "traefik.http.services.excalidraw.loadbalancer.server.port=80"
	container_name: excalidraw
	networks:
	traefik:
	driver: bridge
	name: traefik
	ipam:
	driver: default
	config:
	- subnet: 172.19.0.0/16

view raw excalidraw_https_with_traefik.yaml hosted with ❤ by GitHub

• Run the command and enjoy.

docker-compose up -d

Reference

• Git: excalidraw
